Description
| Mechanical | |
|---|---|
| Dimensions | Ø86 x 153 mm (Ø3.4 x 6") |
| Weight | 700 g (1.5 lb) |
| Enclosure material | Polycarbonate, aluminum alloy |
| Mounting material | Aluminum alloy |
| Weatherproofing | IP67 |
| Optics | |
| Sensor | 1/2" 8MP |
| Lens | F 4.1–12.3 mm; ƒ/1.53–ƒ/3.3 |
| View angle | Wide: H: 109.9°, V: 60°, D: 127.7° Zoom: H: 35°, V: 19.8°, D: 40° |
| Night mode | Built-in IR LED illumination and IR cut filter |
| Video | |
| Resolution | 8MP 3840 x 2160 (16:9) |
| Max. frame rate | 50 FPS |
| Image settings | Flip, brightness, contrast, 50/60 Hz flicker reduction, WDR, hue, infrared, sharpness, saturation, de-noise |
| System | |
| Networking interface | GbE RJ45 port |
| Max. power consumption | 12.5W |
| Power method | PoE |
| Button | Factory reset |
| Mounting | Wall, ceiling, pole mount |
| Ambient operating temperature | -20 to 50° C (-4 to 122° F) |
| Ambient operating humidity | 0 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| Audio | |
| Microphone | Yes (Can be disabled) |
| Software | |
| Web application | UniFi Protect |
| Mobile app | UniFi Protect iOS™ and Android™ |
